HearClear
PNC380s
Performance Characteristics
LTE
FDD:B2/B4/B5/B7/B12/B13/B25/B26
WCDMA: B1/B2/B4/B5/B8
GSM: 850/1900 MHz
WLAN
2.4GHz and 5GHz, 802.11 b/g/n
Bluetooth
BT 4.2
Positioning System
GPS/A-GPS
Standard battery chemistry type:
4000mAh (Li-ion)
Battery life (based on a 5-5-90 duty cycle):
≥24h (5-5-90 working cycle)
Physical Characteristics
Dimensions H x W x D (with standard battery)
5 27/32” x 2 3/8” x1 1/8” (148 x 60 x 28mm)
Weight (with standard battery)
208g
Display
2.0'' 320×240 TFT/Non-touch
Memory
RAM: 1GB ROM: 8GB
Extended: Micro SD/TF card, up to 32GB
SIM Card
Nano SIM 12.3mm x 8.8mm
Ports
Micro USB 2.0
3.5mm Audio Jack
Dock Charger Interface
CAR KIT Connection Interface
User Environment
Operating temperature
-4F to +140F (-20C to +60C)
Storage temperature
-22F to +158F (-30C to +70C)
Mil spec
MIL-STD-810 G Standard
Drop Resistance
1.2m
ESD
IEC 61000-4-2
±8 kV (Contact)
±12 kV (Air)
IP Standards
IP67 Standard
AT&T APPROVED NATIONWIDE COVERAGE PTCRB certified, AT&T approved Network Ready, and fully approved and tested by the leading US carrier for reliable nationwide connectivity
INSTANT GROUP AND INDIVIDUAL CALLING
The PNC380s Push-to-Talk button initiates instant half-duplex group calling or full duplex individual calling. Supports instant group calling from the HALO Dispatch web-based communications and location tracking application
HIGH-DEFINITION LIVE VIDEO
Equipped with an 8 megapixel rear camera, the PNC380S enables real-time video streaming. Video communications improves situational awareness, and facilitates problem solving and decision making
BUILT-IN WI-FI
Built-in Wi-Fi supports in-building communications with seamless switching to LTE networks when outside Wi-Fi range
GPS POSITIONING
Built-in GPS enables real-time tracking and positioning for the dispatch applications
HIGH-QUALITY AUDIO
Digital noise suppression and high-volume speakers for excellent voice quality in loud environments. Provides high-quality digital audio performance for individual calls, group calls, and emergency calls
ERGONOMIC DESIGN
Compact and ergonomic design with easy-access buttons enables comfortable one-hand operation. Reversible belt clip for carrying with screen facing in or out
CAR KIT
Dash-mount car kit available for safe in-vehicle calling. Features optional external speaker, palm microphone, visor microphone and remote Bluetooth Push-to-Talk
BUILT-IN BLUETOOTH
Built-in Bluetooth enables connectivity to earpieces, Push-to-Talk devices, and other wireless accessories
TFT LCD DISPLAY
TFT LCD display provides high-resolution visibility even in bright daylight. Supports an easy-to-use GUI menu system with clean and simple navigation
RELIABLE AND DURABLE
IP67 rated for protection from dust and water ingress up to 1 meter for 30 minutes. Compliant with MIL-STD-810-G for shock and vibration
LONG-LIFE BATTERY
Powerful 4,000mAh Lithium-Ion Polymer battery delivers up to 24 hours of operation
LED FLASHLIGHT
Bright LED illumination at the touch of a button
TEXT MESSAGING
Send, receive, and view text messages between dispatcher and other PoC devices
SAFETY FEATURES
One-touch Emergency button enables one-touch emergency calls to dispatcher and sends alarms to other radios
STUN/REVIVE
Dispatcher can remotely stun (disable) or revive (return to service) if the radio is lost or stolen
Please contact us for more information
|
POA121 Bluetooth Ring PTT |
|
|
SM09S1 External Speaker for Car Kit |
|
|
SM18A3 SM18A3 - Handheld Microphone (designed for connection to Car Kit) |
|
|
EHW06 Bluetooth earpiece |
|
|
CK10 CAR KIT |
|
|
BP4006 Battery |
|
|
RO01 Wrist Strap |
|
|
BC50 Belt Clip for PNC380S |
|
|
BC50 Belt Clip for PNC380S |
|
|
PS2023 Power Adapter - Input: 100-240VAC, Output: 12VDC/2A |
Please contact us for more information
